1986 · Micro Power

Doctor Who and the Mines of Terror

This minisite was curated by unorig, air.

Two routes reach the top score of 32,768: stop the machine by hand, or flood the mine and race the unseen rising level out.

Solution

The top score needs five doublings, and two routes give them all

The game ends when the Doctor leaves the mine, by the escape pod or in the TARDIS. What he carries out, and whether he stopped the heatonite machine, decide the bonus (Gameplay has the table). Each map button opens the place on the Maps tab.

Two routes to the top score

The bonus starts at 1024 and doubles five times at most, to 32,768: once each for the CRYSTAL, the CAPSULE, and Splinx carried out, once for the machine stopped, and once for leaving in the TARDIS ($9163-$91BC). The machine can be stopped two ways, and either counts once, so there are two routes to that score. Neither needs the AIR MASK, the PICK AXE, the BOX, the DETONATOR, or the ACTIVATOR.

  1. Halt the machine. Keep Splinx, get the SPANNER , drop the CHEMICALS in the pool, and leave the MAT at the bottom of the stairs. Work the code lock for the PASS CARD , fetch the O and P CIRCUITs from the dome, and spell STOP at the machine, keeping the A or the R. Then take the CRYSTAL and the CAPSULE home in the TARDIS. Step through the machine and the way home on the map.
  2. Flood the mine. Set the EXPLOSIVES off with F5 at the low point on the right . The rising level counts as the machine stopped, so the CIRCUITs are not needed for it ($91AB). The PASS CARD still is: a security gate stands between the lift and the TARDIS. Collect Splinx, the CRYSTAL, and the CAPSULE first and blow the EXPLOSIVES last: the level rises 8 pixels every 128 frames, about every two and a half seconds, so from the flood point there is about half a minute before it reaches the Doctor, and GAME OVER if it does ($C0C2, fuse_update, $C09A). The game never draws the water: the only sign is a ticking sound (sound 3) that plays while the level rises, so the Doctor cannot see how close it is. Head straight up to the TARDIS once the fuse is lit.

The route on the map

Step through the whole top-score route, from the TARDIS landing to going home. Every leg is plotted over the map's walls, floors, ladders, stairs, lift, hatches, and gates.

The steps

StepHow
Keep Splinx Splinx must be in the Doctor's hands at the end ($917F). Following him out does not count.
Take the CRYSTAL Held or pocketed at the end ($916F). The Master comes for the crystal, even from a pocket, and carries it away ($B48A), so the crystal needs watching once the Doctor has it. If the Master gets it, he leaves it high in the mine ($B587).
Take the CAPSULE Held or pocketed at the end ($9177).
Halt the heatonite machine At the start five CIRCUITs sit in the five slots, their letters spell START, and the machine runs. Take out the A and the R in slots 3 and 4, and put in their place the O and the P found elsewhere: and . The Doctor can only reach them once he holds the , so get it first; see the code lock. When slots 1 to 4 spell STOP (S $40, either T $41 or $4A, O $44, P $45, the letters wanted at $B989), the machine stops and a sound plays (machinery_update, $B9B6, checked only in that part of the mine). Spelling START again starts it again ($BA06). At the end the Doctor must carry one of the CIRCUITs $41, $42, $43, or $4A for the halt to count ($9190-$91A1).
Or flood the mine The EXPLOSIVES blown at this point start a level rising, one step every 128 frames ($C22B). The rising level also counts as the machine halted at the end ($91AB), but the level kills the Doctor if it reaches him ($C0C2).
Leave in the TARDIS With nothing in his hands, the Doctor presses F5 standing on the TARDIS (block $B2, use_empty_hands, $BD1B). The map has a TARDIS in two places. The one he lands in is removed as soon as he goes right of x $0800 ($BADD), so the way home is the other one. This doubles the bonus once more.
Or the escape pod Holding the , F5 at one of three points ends the game without the TARDIS doubling (use_activator, $BCE0).

What is in the way

ObstacleWhat gets past it
Rock at three dig sitesThe , three hits at each
Eight clamps on ladders high in the mineThe at each bolt
Bad air in four blocks high in the mineThe held in the hand
The security gateHolding the sets the terrain class of character $A0 to 0 instead of 1 ($BB15), which opens the gate. The map has five gates, all block $20, at rows 24, 38, and 50
The walled-up doorway, if controller $22 took the Doctor prisonerA blast at ($C22E); from the EXPLOSIVES or a DETONATOR, armed with F5. See the prisoner on Gameplay
The wall in front of the PASS CARD, beside the code lock's buttonsThe code, from the code card; see the code lock below
The madrag, guarding the way to the AIR MASKSplinx carrying off one of her eggs; see past the madrag below
The floor sensor map, which sends controller $23 after the DoctorThe MAT map left at the bottom of the stairs, which stops the controller; see the sensor on Gameplay
Controllers, stalagmites, falls, and the eggsKept away from; Gameplay covers each

The madrag

Lure the madrag away by having Splinx steal an egg

The madrag guards her nest at the bottom of the mine, and she chases the Doctor when he comes within 160 pixels of her (madrag_spot_doctor, $B933). If she reaches him, she bites, and he loses a regeneration. She has one weakness: when one of her is moved, she goes after it and carries it back to the nest, even when Splinx holds it ($B752). So the way past her is to let Splinx take an egg and draw her off.

Before any of this, the Doctor needs the , and the Rijans mining at the bottom left of the mine have it.9 Three of them pass it from one to the next: a miner carries it home and puts it down there for a partner to collect (trio_go_home, $C373; trio_state7_seek_obj34, $C30A). The Doctor waits for one miner to put it down and takes it before the next one picks it up.

The Doctor throws a marker onto one of her with F7, so that he never goes near the egg himself, and drops a second marker by the ladder to the left. He climbs into place just above the madrag and programs Splinx: 1 GOTO MARKER, P PICK UP OBJECT, and 2 GOTO MARKER.

When Splinx carries the egg away, the madrag goes after the robot cat. While she is away, the Doctor drops down, takes the PICK AXE in hand, breaks the rock at the two there, and goes right to the mask.

Getting past her matters because the lies behind rock to the right of her nest, and the Doctor needs it to breathe the bad air high in the mine.

The Master

Let Splinx carry the CRYSTAL past the Master

Once the Doctor has the , the Master comes for it. He takes it from the Doctor's hands or even from a pocket ($B48A, $B520-$B535), and knocks the Doctor flat for a count of 121 ($B544, $CB60).

The Master then walks off with the crystal to a door at x $0DA8, y $0380, which opens for him ($B5AD). The crystal is not lost: it turns up high in the mine at x $06C8, y $06A8, free to be taken again ($B587).

The way past him is to let Splinx carry the crystal instead.911 The crystal still doubles the bonus at the end while Splinx holds it ($928C).

The code lock

Secret: only the code card in the box can read the lock

Halfway up the mine is a panel that gives three clues, and below it three buttons that each show a shape. The answer is six shapes long, and the only way to find it is the code card that came with the game.

The code card: coloured triangles, squares, circles, crosses, diamonds and question marks in white, red, blue, green, and yellow bands around a large green diamond, on a black ground with coloured lines
The code card from the game's box. Its diamond bands hold the same list as the game: from the white triangle at the top corner, the outer band reads white triangle, red square, red circle, blue square, green triangle, red cross, white diamond, the first seven entries of the list at $BD6F.

The Doctor works the lock with empty hands and F5 (code_lock_press, $BE29). Standing at the clue panel, each press shows the next clue: a number from 1 to 5, a shape, and a letter ($BE6F). The letters are W, R, B, G, and Y, which match white, red, blue, green, and yellow, the colours of the lines on the card. Standing at the buttons, he presses the one showing the next shape of the answer. One button always shows it and the other two show other shapes (code_lock_deal_buttons, $BEEC). A wrong press deals a whole new code with new clues ($BED5), so guessing gives a one-in-three chance six times running.

The card is in the game too, as 186 bytes at $BD6F. Each byte is a coloured shape: eight times the colour plus the shape. To deal a code, the game takes three numbers from the frame counter (code_lock_new_sequence, $BF69), finds that colour and shape in the list, skips to the occurrence the number names, and reads six shapes from there ($BFC7). So the first shape of the answer is always the shape in the clue. The first empty-handed F5 of a game deals the first code ($BB49).

Choose the three clues, or deal one the way the game does. The answer is read from the list at code_lock_deck ($BD6F-$BE28), drawn here 31 to a row, with the six shapes of the answer boxed. The shapes are the game's own characters: $FD $FA $FE $FB $FC $FF for shapes 0-5 ($BD64), $F6 $F5 $F7 $F8 $F9 for the letters ($BD5F) and $A1-$A5 for the numbers ($BD6A), from the graphics set the hand-over image holds.

The clues never show the sixth shape, but answers can contain it: the frame counter is reduced to 0-4 for each clue, and the list uses all six shapes. Every colour and shape the clues can show turns up at least five times, so every clue has an answer.

Six right presses open the wall to the right of the buttons. The game plays a sound and redraws the block there (switch cell 13: block $C2 becomes $D5, $BF59), and the column of wall at its left edge becomes open floor. Behind it lies the PASS CARD, which opens the security gates when the Doctor holds it. After that the buttons do nothing.

The room around the lock, row 38 to row 47, columns 77 to 85, before (left) and after (right) the code is entered. The clue panel is the framed door at the top; the buttons are drawn onto the screen while the Doctor is there and are not part of the map.

The way to the lock is shut by a hatch that only the SPANNER map opens, so the order is the SPANNER, then the MAT, then the PASS CARD, and only then the O and P CIRCUITs behind the gates.

Get the MAT map before going to the lock, and drop it at the bottom of the stairs. Otherwise the floor sensor sends a controller after the Doctor while he works the buttons.

Step through the way to the PASS CARD on the map.
